New C6C

NPK Compactors
C6C
REQUEST A QUOTE

The C6C plate compactor is compatible with backhoes and/or full size excavators in the 8-21 ton range.  Compatible on John Deere excavator sizes 75-160 and John Deere 710 backhoe.


More Info

Recommended Carrier Weight 8 - 21 US tons 7.2 - 19 metric tons
Working Weight fixed: 1,535 lbs swivel: 1,715 lbs fixed: 696 kg swivel: 778 kg
Impulse Force 16,000 lbf
Cycles per Minute 2,200 rpm
Oil Flow 33 gpm 125 lpm
Operating Pressure 1,800 - 2,300 psi 124 - 159 bar
Relief Pressure Setting 2,600 psi 179 bar
Swivel Feature optional
Baseplate Dimensions 29 x 40 in 737 - 1,016 mm
Compaction Area 8.1 sq ft 0.75 sq m
Height 39 in 991 mm
Width 29 in 737 mm
Chuck Opening N/A
Chuck Oil Flow N/A
Chuck Pressure N/A

NPK C6C Plate Compactor / Driver with Foot Extension - Backfilling Deep, Narrow Trench
