New PH3

NPK Hammers
PH3
REQUEST A QUOTE

The PH3 hydraulic hammer is compatible with skid steers, backhoes and/or mini excavators in the 4-8 ton range. Compatible on John Deere mini excavator sizes 50-85, with the most common size being the 60.  Also compatible with all John Deere skidsteers, and 310-410 backhoes


More Info

Working Weight 990 lbs 450 kg
Recommended Carrier Weight 4 - 8 US tons 3.6 - 7.3 metric tons
Impact Energy Class 750 ft lbs
Impact Frequency 500 - 1,150 bpm
Oil Flow 12 - 26 gpm 45 - 100 lpm
Operating Pressure 2,465 psi 170 bar
Tool Diameter 3 in 76 mm
Tool Working Length 16.5 in 419 mm

NPK PH3 Skid Steer Mounted Hammer - Sidewalk Repairs
